R681-W3K-12V
R681
- Checking stock...
R681-W3K-12V Shallow Retrofit White 3000K 12V AC/DC
Lumens
Watts
170lm
3W
View Options
Add Driver
driver not included
View Options
Select Cabinet & Display
R681
Shallow Retrofit White 3000K 12V AC/DC
Temp.
3000K Warm White
Cut out
60mm
Lumens
170lm
Watts
3W
R681
Shallow Retrofit White 4000K 12V AC/DC
Temp.
4000K Natural White
Cut out
60mm
Lumens
170lm
Watts
3W
R681
Shallow Retrofit Satin Chrome 3000K 12V AC/DC
Temp.
3000K Warm White
Cut out
60mm
Lumens
170lm
Watts
3W
R681
Shallow Retrofit Satin Chrome 4000K 12V AC/DC
Temp.
4000K Natural White
Cut out
60mm
Lumens
170lm
Watts
3W
R681
Shallow Retrofit Black 3000K 12V AC/DC
Temp.
3000K Warm White
Cut out
60mm
Lumens
170lm
Watts
3W
R681
Shallow Retrofit Black 4000K 12V AC/DC
Temp.
4000K Natural White
Cut out
60mm
Lumens
170lm
Watts
3W
Select driver
driver sold separately. Please select below.
Non Dimmable
DCV12-M-12W-IP
IP65 12V 12W Constant Voltage Mini Non-dimmable Driver
Watts
0W-12W
Other
ULTRA70W
0-70W Electronic Transformer
Watts
0-70W
ULTRA105W
0-105W Electronic Transformer
Watts
0-105W
Specifications
Cut Out
60mm
Finish
White
Colour Temp
3000K Warm White
Watts
3W
Lumens
170lm
Beam Angle
110°
Input
12V
Dimming / Control
Dimmable
CRI
90
Lifespan
60,000hrs (L80 B10)
Ingress Protection
IP54
Diameter
70mm
Height
15mm
Binning
SDCM 3
Classification
IC-F / IC-4
Height Clearance to Building Elements
0mm
Side Clearance to Building Elements
0mm
Material
Aluminium
Electrical Class
Class III
Driver
Not included, Driver sold separately
Installation Note
Suitable for zero clearance installs
Warranty
5 Year Warranty
Driver
None
Resources
