Cevon M80 Type 4 Dark Art Fixed High Output High Gloss Black 4000K

M80 Series

Select your M80-T4

22 items

M80-T1
Cevon M80 Type 1 Dark Art Adjustable Black 3000K
Watts9W
Lumens730lm
Tilt Angle25°
Rotate Angle355°
M80-T2
Cevon M80 Type 2 Lotus Black 3000K
Watts12W
Lumens820lm
M80-T3
Cevon M80 Type 3 Dark Art Fixed Black 3000K
Watts12W
Lumens1110lm
M80-T4
Cevon M80 Type 4 Dark Art Fixed High Output Black 3000K
Watts17W
Lumens1390lm
M80-T5
Cevon M80 Type 5 Dark Art Adj Spot Black 3000K
Watts9.5W
Lumens700lm
Tilt Angle38°
Rotate Angle355°
M80-T6
Cevon M80 Type 6 Black Hole Black Trim 3000K
Watts12W
Lumens880lm
M80-T7
Cevon M80 Type 7 Adjustable Highlighter Black Trim 3000K
Watts9.5W
Lumens630lm
Tilt Angle30°
Rotate Angle355°
M80-T8
Cevon M80 Type 8 Dark Art Adjustable Scopic Black 3000K 55D
Watts11W
Lumens755lm
Tilt Angle40°
Rotate Angle360°
M80-T9
Cevon M80 Type 9 Pinpoint Black Trim 3000K
Watts12.5W
Lumens570lm
M80-T10
Cevon M80 Type 10 Wallwasher Black Trim 3000K
Watts12W
Lumens885lm
M80-T11
Cevon M80 Type 11 Classico Fixed Black 3000K
Watts12W
Lumens1110lm
M80-T12
Cevon M80 Type 12 Classico Adjustable Black 3000K
Watts12W
Lumens1110lm
Tilt Angle20°
Rotate Angle355°
M80-T13
Cevon M80 Type 13 Dark Art Spot Black 3000K
Watts12W
Lumens910lm
Tilt Angle40°
Rotate Angle355°
M80-T15
Cevon M80 Type 15 Dark Art Sphere Black 3000K
Watts9W
Lumens760lm
Tilt Angle60°
Rotate Angle355°
M80-T16
Cevon M80 Type 16 Dark Art Sphere Black 3000K
Watts12W
Lumens975lm
Tilt Angle60°
Rotate Angle355°
M80-T18
Cevon M80 Type 18 Dark Art Adj Spot Black 3000K
Watts9W
Lumens730lm
Tilt Angle90°
Rotate Angle355°
M80-T19
Cevon M80 Type 19 Dark Art Adj Spot Black 3000K
Watts17W
Lumens1370lm
Tilt Angle90°
Rotate Angle355°
M80-T21
Cevon M80 Type 21 Adjustable Spot Black 3000K
Watts24W
Lumens2500lm
Tilt Angle90°
Rotate Angle355°
M80-T22
Cevon M80 Type 22 Dark Art Pendant Spot Black 3000K
Watts12W
Lumens1020lm
M80-T23
Cevon M80 Type 23 Dark Art Pendant Spot Black 3000K
Watts17W
Lumens1370lm
M80-T25
Cevon M80 Type 25 Dark Art Pendant Spot Black 3000K
Watts9W
Lumens760lm
M80-T26
Cevon M80 Type 26 Dark Art Pendant Spot Black 3000K
Watts12W
Lumens975lm
Back
Cevon M80 Type 4 Dark Art Fixed High Output High Gloss Black 4000K
Jump to Resources
Cevon M80 Type 4 Dark Art Fixed High Output High Gloss Black 4000K

M80-T4

Cevon Type 4 Module - Dark Art Fixed High Output 17W 4000K 500mA 36° High Gloss Black
  • Custom Build - Request Availability

Configure your M80-T4 10 options

Finish: Black
Module
Cevon M80 Type 4 Dark Art Fixed High Output High Gloss Black 4000K

M80-T4-HGB4K-36D Cevon M80 Type 4 Dark Art Fixed High Output High Gloss Black 4000K

Lumens

Watts

1445lm

17W

Frame

Not included

Please select from options

Driver

Not included

Please select from options

Jump to Resources

Add to

Jump to

Specifications Downloads

Select Module

Cevon M80 Type 4 Dark Art Fixed High Output White 3000K

M80-T4

View Details Selected

Cevon M80 Type 4 Dark Art Fixed High Output White 3000K

Temp.

3000K Warm White

Lumens

1500lm

Watts

17W

Cevon M80 Type 4 Dark Art Fixed High Output White 4000K

M80-T4

View Details Selected

Cevon M80 Type 4 Dark Art Fixed High Output White 4000K

Temp.

4000K Natural White

Lumens

1685lm

Watts

17W

Cevon M80 Type 4 Dark Art Fixed High Output Black 3000K

M80-T4

View Details Selected

Cevon M80 Type 4 Dark Art Fixed High Output Black 3000K

Temp.

3000K Warm White

Lumens

1390lm

Watts

17W

Cevon M80 Type 4 Dark Art Fixed High Output Black 4000K

M80-T4

View Details Selected

Cevon M80 Type 4 Dark Art Fixed High Output Black 4000K

Temp.

4000K Natural White

Lumens

1525lm

Watts

17W

Cevon M80 Type 4 Dark Art Fixed High Output Gold 3000K

M80-T4

View Details Selected

Cevon M80 Type 4 Dark Art Fixed High Output Gold 3000K

Temp.

3000K Warm White

Lumens

1390lm

Watts

17W

Cevon M80 Type 4 Dark Art Fixed High Output Gold 4000K

M80-T4

View Details Selected

Cevon M80 Type 4 Dark Art Fixed High Output Gold 4000K

Temp.

4000K Natural White

Lumens

1445lm

Watts

17W

Cevon M80 Type 4 Dark Art Fixed High Output High Gloss Black 3000K

M80-T4

View Details Selected

Cevon M80 Type 4 Dark Art Fixed High Output High Gloss Black 3000K

Temp.

3000K Warm White

Lumens

1390lm

Watts

17W

Cevon M80 Type 4 Dark Art Fixed High Output High Gloss Black 4000K

M80-T4

View Details Selected

Cevon M80 Type 4 Dark Art Fixed High Output High Gloss Black 4000K

Temp.

4000K Natural White

Lumens

1445lm

Watts

17W

Cevon M80 Type 4 Dark Art Fixed High Output Silver 3000K

M80-T4

View Details Selected

Cevon M80 Type 4 Dark Art Fixed High Output Silver 3000K

Temp.

3000K Warm White

Lumens

1500lm

Watts

17W

Cevon M80 Type 4 Dark Art Fixed High Output Silver 4000K

M80-T4

View Details Selected

Cevon M80 Type 4 Dark Art Fixed High Output Silver 4000K

Temp.

4000K Natural White

Lumens

1940lm

Watts

17W

Select Frame

Frame sold separately. Please select below.

Cevon Type Recessed Round Frame for M80 Black

F80-RR

View Details Selected

Cevon Type Recessed Round Frame for M80 Black

Cut out

Ø95mm

Cevon Type Recessed Round Frame for M80 White

F80-RR

View Details Selected

Cevon Type Recessed Round Frame for M80 White

Cut out

Ø95mm

Cevon Recessed Oval Double Frame for M80 Black

F80-RR2

View Details Selected

Cevon Recessed Oval Double Frame for M80 Black

Cut out

2xØ95mm @ 90mm centres

Cevon Recessed Oval Double Frame for M80 White

F80-RR2

View Details Selected

Cevon Recessed Oval Double Frame for M80 White

Cut out

2xØ95mm @ 90mm centres

Cevon Recessed Square Frame for M80 Black

F80-RSQ

View Details Selected

Cevon Recessed Square Frame for M80 Black

Cut out

Ø95mm

Cevon Recessed Square Frame for M80 White

F80-RSQ

View Details Selected

Cevon Recessed Square Frame for M80 White

Cut out

Ø95mm

Cevon Recessed Rectangular Double Frame for M80 Black

F80-RSQ2

View Details Selected

Cevon Recessed Rectangular Double Frame for M80 Black

Cut out

2xØ95mm @ 90mm centres

Cevon Recessed Rectangular Double Frame for M80 White

F80-RSQ2

View Details Selected

Cevon Recessed Rectangular Double Frame for M80 White

Cut out

2xØ95mm @ 90mm centres

Cevon Type Trimless Frame for M80 White

F80-TL

View Details Selected

Cevon Type Trimless Frame for M80 White

Cut out

Ø130mm

Cevon Type Surface Cylinder for M80 Black

SF80-RR

View Details Selected

Cevon Type Surface Cylinder for M80 Black

Cevon Type Surface Cylinder for M80 White

SF80-RR

View Details Selected

Cevon Type Surface Cylinder for M80 White

Select driver

driver sold separately. Please select below.

Dimmable

500mA 20W Dimmable Constant Current DX Series Driver

DCC500-DX-20W

View Details Selected

500mA 20W Dimmable Constant Current DX Series Driver

Watts

10W-20W

Dali

260-700mA 25W Constant Current Dali Driver

DCC260700-DD-1625W

View Details Selected

260-700mA 25W Constant Current Dali Driver

Watts

16W-25W

Casambi

260-700mA 25W Constant Current Casambi Driver

DCC260700-CAS-1325W

View Details Selected

260-700mA 25W Constant Current Casambi Driver

Watts

13W-25W

Specifications

M80-T4-HGB4K-36D

Finish

Black, High Gloss Black

Colour Temp

4000K Natural White

Watts

17W

Lumens

1445lm

Beam Angle

36°

Dimming / Control

Dimmable

CRI

97

Lifespan

105,000hrs (L90 B10)

Ingress Protection

IP43

Diameter

Ø78mm

Height

100mm

Binning

SDCM 2

Classification

IC

Material

Aluminium

Electrical Class

Class III

Driver Output Current

500mA

Driver

Not included, Driver sold separately

Warranty

5 Year Warranty

Specifications

M80-T4-HGB4K-36D

Specifications

None
