R647 WL
R647
- Checking stock...
R647 WL Exterior Narrow Beam Small Effect Downlight White 3000K
Lumens
Watts
82lm
1.2W
View Options
Add Driver
driver not included
View Options
Select Multi-Use Effect
R647
Exterior Narrow Beam Small Effect Downlight White 3000K
Temp.
3000K
Cut out
32mm
Lumens
82lm
Watts
1.2W
R647
Exterior Narrow Beam Small Effect Downlight Black 3000K
Temp.
3000K Warm White
Cut out
32mm
Lumens
82lm
Watts
1.2W
R647
Exterior Narrow Beam Small Effect Downlight Stainless Steel 3000K
Temp.
3000K Warm White
Cut out
32mm
Lumens
82lm
Watts
1.2W
Select driver
driver sold separately. Please select below.
Dimmable
DCC350-DM-4W-IP
IP65 350mA 4W Constant Current Mini Dimmable Driver
Watts
2W-4W
DCC350-DM-10W-IP
IP65 350mA 10W Constant Current Mini Dimmable Driver
Watts
5W-10W
DCC350-DX-6W
350mA 6W Dimmable Constant Current DX Series Driver
Watts
3.5W-6W
DCC350-DX-9W
350mA 9W Dimmable Constant Current DX Series Driver
Watts
4.5W-9W
DCC350-DX-12W
350mA 12W Dimmable Constant Current DX Series Driver
Watts
6W-12W
DCC350-DX-20W
350mA 20W Dimmable Constant Current DX Series Driver
Watts
10W-20W
Non Dimmable
DCC350-M-4W-IP
IP65 350mA 4W Constant Current Mini Non-dimmable Driver
Watts
1W-4W
DCC350-M-12W-IP
IP65 350mA 12W Constant Current Mini Non-dimmable Driver
Watts
6W-12W
DCC350-6W
350mA 6W Constant Current Non-dimmable Driver
Watts
3W-6W
DCC350-12W
350mA 12W Constant Current Non-dimmable Driver
Watts
1W-12W
DCC350-20W
350mA 20W Constant Current Non-dimmable Driver
Watts
1W-20W
Specifications
Colour Temp
3000K
Watts
1.2W
Lumens
82lm
Beam Angle
24°
Input
350mA
Dimming / Control
Dimmable
CRI
80
Lifespan
42,000hrs (L70)
Ingress Protection
IP65
Cut Out
32mm
Diameter
40mm
Height
34.5mm
Classification
IC
Height Clearance to Building Elements
0mm
Side Clearance to Building Elements
0mm
Material
316 Stainless Steel
Electrical Class
Class III
Driver Output Current
350mA
Driver Included / Incorporated
Driver not included, sold separately
Warranty
5 Year Warranty
Driver
None
