M81-T1-BS27K-45D
M81-T1
- Custom Build - Request Availability
M81-T1-BS27K-45D Cevon M81 Type 1 Dark Art Square Adj Black, Silver 2700K
Lumens
Watts
Tilt Angle
735lm
9W
25°
View Options
Add Frame
Frame not included
View Options
Add Driver
driver not included
View Options
Select Module
M81-T1
Cevon M81 Type 1 Dark Art Square Adj Black, Silver 2700K
Temp.
2700K Warm White
Tilt Angle
25°
Lumens
735lm
Rotate Angle
355°
Watts
9W
M81-T1
Cevon M81 Type 1 Dark Art Square Adj White 2700K
M81-T1
Cevon M81 Type 1 Dark Art Square Adj White 3000K
Temp.
3000K Warm White
Tilt Angle
25°
Lumens
750lm
Rotate Angle
355°
Watts
9W
M81-T1
Cevon M81 Type 1 Dark Art Square Adj White, Black 2700K
Temp.
2700K Warm White
Tilt Angle
25°
Lumens
730lm
Rotate Angle
355°
Watts
9W
M81-T1
Cevon M81 Type 1 Dark Art Square Adj White, Black 3000K
Temp.
3000K Warm White
Tilt Angle
25°
Lumens
730lm
Rotate Angle
355°
Watts
9W
M81-T1
Cevon M81 Type 1 Dark Art Square Adj White, Gold 2700K
Temp.
2700K Warm White
Tilt Angle
25°
Lumens
730lm
Rotate Angle
355°
Watts
9W
M81-T1
Cevon M81 Type 1 Dark Art Square Adj White, Gold 3000K
Temp.
3000K Warm White
Tilt Angle
25°
Lumens
730lm
Rotate Angle
355°
Watts
9W
M81-T1
Cevon M81 Type 1 Dark Art Square Adj White, High Gloss Black 2700K
Temp.
2700K Warm White
Tilt Angle
25°
Lumens
730lm
Rotate Angle
355°
Watts
9W
M81-T1
Cevon M81 Type 1 Dark Art Square Adj White, High Gloss Black 3000K
Temp.
3000K Warm White
Tilt Angle
25°
Lumens
730lm
Rotate Angle
355°
Watts
9W
M81-T1
Cevon M81 Type 1 Dark Art Square Adj White, Silver 2700K
Temp.
2700K Warm White
Tilt Angle
25°
Lumens
735lm
Rotate Angle
355°
Watts
9W
M81-T1
Cevon M81 Type 1 Dark Art Square Adj White, Silver 3000K
Temp.
3000K Warm White
Tilt Angle
25°
Lumens
750lm
Rotate Angle
355°
Watts
9W
M81-T1
Cevon M81 Type 1 Dark Art Square Adj Black 2700K
Temp.
2700K Warm White
Tilt Angle
25°
Lumens
730lm
Rotate Angle
355°
Watts
9W
M81-T1
Cevon M81 Type 1 Dark Art Square Adj Black 3000K
Temp.
3000K Warm White
Tilt Angle
25°
Lumens
730lm
Rotate Angle
355°
Watts
9W
M81-T1
Cevon M81 Type 1 Dark Art Square Adj Black, Gold 2700K
Temp.
2700K Warm White
Tilt Angle
25°
Lumens
730lm
Rotate Angle
355°
Watts
9W
M81-T1
Cevon M81 Type 1 Dark Art Square Adj Black, Gold 3000K
Temp.
3000K Warm White
Tilt Angle
25°
Lumens
730lm
Rotate Angle
355°
Watts
9W
M81-T1
Cevon M81 Type 1 Dark Art Square Adj Black, High Gloss Black 2700K
Temp.
2700K Warm White
Tilt Angle
25°
Lumens
730lm
Rotate Angle
355°
Watts
9W
M81-T1
Cevon M81 Type 1 Dark Art Square Adj Black, High Gloss Black 3000K
Temp.
3000K Warm White
Tilt Angle
25°
Lumens
730lm
Rotate Angle
355°
Watts
9W
M81-T1
Cevon M81 Type 1 Dark Art Square Adj Black, Silver 3000K
Temp.
3000K Warm White
Tilt Angle
25°
Lumens
750lm
Rotate Angle
355°
Watts
9W
Select Frame
Frame sold separately. Please select below.
F81-SQ
Cevon Type Recessed Square Frame for M81 Black
Cut out
95 x 95mm
F81-SQ
Cevon Type Recessed Square Frame for M81 White
Cut out
95 x 95mm
F81-SQ2
Cevon Type Recessed Rectangular Double Frame for M81 Black
Cut out
173 x 95mm
F81-SQ2
Cevon Type Recessed Rectangular Double Frame for M81 White
Cut out
173 x 95mm
F81-TL-SQ
Cevon Type Trimless Square Frame for M81
Cut out
130 x 130mm
F81-TL-SQ2
Cevon Type Trimless Rectangular Double Frame for M81
Cut out
177 x 94mm
SF81
Cevon Type Surface Square Box for M81 Black
SF81
Cevon Type Surface Square Box for M81 White
Select driver
driver sold separately. Please select below.
Dimmable
DCC260-DX-12W
260mA 12W Dimmable Constant Current DX Series Driver
Watts
6W-12W
Dali
DCC180500-DD-1012W
180-500mA 12W Constant Current Dali Driver
Watts
10W-12W
Casambi
DCC260700-CAS-1325W
260-700mA 25W Constant Current Casambi Driver
Watts
13W-25W
Specifications
Finish
Black, Silver
Colour Temp
2700K Warm White
Watts
9W
Lumens
735lm
Beam Angle
45°
Dimming / Control
Dimmable
CRI
97
Lifespan
105,000hrs (L90 B10)
Tilt Angle
25°
Rotate Angle
355°
Height
70mm
Width
78mm
Length
78mm
Binning
SDCM 2
UGR
Suitable for installations requiring UGR of less than 19
Classification
IC
Material
Aluminium
Electrical Class
Class III
Driver Output Current
260mA
Driver Included / Incorporated
Driver not included, sold separately
Warranty
5 Year Warranty
Frame
None
Driver
None
