R252-W34KA
R252
- Checking stock...
R252-W34KA 12x6 Proline Panel V2 - 3K/4K Standard White
Lumens
Watts
3300lm, 4250lm, 4880lm or 5520lm (Selectable)
26W, 34W, 40W or 46W
View Options
-
12x6 Surface Mount Kit White
-
12x6 Recessed Frame Kit White
-
12x3 & 12x6 Suspension Kit Stainless Steel
-
Cable Restraint 300mm (4 pack)
Select Panels
R252
12x6 Proline Panel V2 - 3K/4K Standard White
Temp.
3000K or 4000K (Selectable)
Lumens
3300lm, 4250lm, 4880lm or 5520lm (Selectable)
Watts
26W, 34W, 40W or 46W
R252
12x6 Proline Panel V2 - 4K/57K Standard White
Temp.
4000K or 5700K (Selectable)
Lumens
3300lm, 4250lm, 4880lm or 5520lm (Selectable)
Watts
26W, 34W, 40W or 46W
Specifications
Finish
White
Colour Temp
3000K or 4000K (Selectable)
Watts
26W, 34W, 40W or 46W
Lumens
3300lm, 4250lm, 4880lm or 5520lm (Selectable)
Beam Angle
90°
Input
220-240V 50/60Hz
Dimming / Control
Non-Dimmable
CRI
90
Lifespan
60,000hrs (L80 B10)
Ingress Protection
IP44 (IP20 Rear)
RAL Colour
RAL9016
Height
33mm
Width
595mm
Length
1195mm
Binning
SDCM 3
TLAs
Flicker-free (PstLM <1.0 / SVM >0.4)
UGR
Suitable for installations requiring UGR of less than 19
Classification
IC-F, Driver must be installed above insulation
Material
Aluminium, SPCC, PS
Electrical Class
Class II
Driver Included / Incorporated
Driver Included
Ambient Operating Temperature
-20... +40°C
Power Factor
0
Warranty
5 Year Warranty
