550-700mA 5W Constant Current Mini Slim Phase-cut Dimmable Driver

DCC550700-DMS-4W5W

All DCC550700-DMS-4W5W

DCC550700-DMS-4W5W

  • Checking stock...
Driver Mini Slim Phase-Cut Dimmable Pri:240V Sec:2.5-7V 550-700mA CC 4-5W Pre-wired Primary and secondary
Dimmable (phase-cut)
550-700mA 5W Constant Current Mini Slim Phase-cut Dimmable Driver

DCC550700-DMS-4W5W 550-700mA 5W Constant Current Mini Slim Phase-cut Dimmable Driver

Watts

4W-5W

Watts

4W-5W

Add to

Jump to

Specifications Downloads

Select driver

driver sold separately. Please select below.

Specifications

550-700mA 5W Constant Current Mini Slim Phase-cut Dimmable Driver

Dimmable (phase-cut)

DCC550700-DMS-4W5W

Watts

4W-5W

Input

220-240V 50/60Hz

Dimming / Control

Phase-Cut Dimmable

Ingress Protection

IP20

Height

18.5mm

Width

20mm

Length

100mm

Material

Self-extinguishing Plastic Housing

Electrical Class

Class II

Driver Output Voltage

2.5V-7V

Driver Output Current

Adjustable 550mA, 600mA, 650mA, 700mA

Power Factor

0.90C

Installation Note

Must be installed above insulation

Warranty

5 Year Warranty
