1500mm Quad Wattage Wide Body Batten 4000K / 6000K

LED445-W46

All Interior Battens LED445-W46

LED445

  • Checking stock...
Batten Wide Body 1500mm 37-70W Pri:240V 4/6K IP54 CRI90
Battens
1500mm Quad Wattage Wide Body Batten 4000K / 6000K

LED445-W46 1500mm Quad Wattage Wide Body Batten 4000K / 6000K

Lumens

Watts

5000lm / 6050lm / 7150lm / 8225lm

37W / 46W / 56W / 70W

Lumens

Watts

5000lm / 6050lm / 7150lm / 8225lm

37W / 46W / 56W / 70W

Add to

Jump to

Specifications Downloads

Select driver

driver sold separately. Please select below.

Specifications

1500mm Quad Wattage Wide Body Batten 4000K / 6000K

Battens

LED445-W46

Finish

White

Colour Temp

4000K or 6000K (Selectable)

Watts

37W / 46W / 56W / 70W

Lumens

5000lm / 6050lm / 7150lm / 8225lm

Beam Angle

120°

Input

220-240V 50/60Hz

CRI

90

Lifespan

72,000hrs (L80 B10)

Ingress Protection

IP54

RAL Colour

W002

Height

82mm

Width

163mm

Length

1500mm

Binning

SDCM 3

TLAs

Flicker-free (PstLM <1.0 / SVM >0.4)

Material

SPCC (Steel), PC Plastic

Electrical Class

Class I luminaire, requires earth

Driver Included / Incorporated

Driver Incorporated

Warranty

5 Year Warranty
